TPC-BF5300-7 | DAHUA - Cámara Térmica | 7 mm

Thermal Camera

Image Sensor

Uncooled VOx Microbolometer

Effective Pixels

336(H)x256(V)

Pixel Size

17um

Thermal Sensitivity(NETD)

<40mK@f/1.0

Spectral Range

7~14um

Image Setting

Brightness/Sharpness/ROI/AGC/FFC/3D DNR

Color Palettes

14(Whitehot/Blackhot/Ironrow/Icefire/

Fusion/Rainbow/Globow/Iconbow1/

Iconbow2 .etc)

Thermal Lens

Lens Type

Fixed

Focus Control

Athermalized, Focus-free

Focal Length

7.5mm

13mm

19mm

25mm

35mm

Angle of View

H: 45°

V: 35°

H: 25°

V: 19°

H: 17°

V: 13°

H: 13°

V: 10°

H: 9.3°

V: 7.1°

Effective Distance①

Man(1.8m*0.5m)

D②: 240m

R③: 60m

I ④: 30m

D: 450m

R: 110m

I: 60m

D: 640m

R: 160m

I: 80m

D: 1000m

R: 250m

I: 125m

D: 1300m

R: 320m

I: 160m

Effective Distance

Vehicle(2.3m*2.3m)

D: 720m

R: 180m

I: 90m

D: 1300m

R: 350m

I: 180m

D: 2000m

R: 500m

I: 250m

D: 3000m

R: 720m

I: 360m

D: 4000m

R: 1000m

I: 500m

Compression

H.264/MJPEG

Frame Rate

Main Stream:

1280*1024 (default)/720P @1 ~ 25/30fps

Sub Stream:

640*512 (default)/320*256 @1 ~ 25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 640 ~ 8192Kbps

Motion Detetion

Off/On (4 zone, Rectangle)

Region of Interest

Off/On (4 zone)

Electronic Image Stabilization

(EIS)

NA

Digital Zoom

16x

Flip

180°

Mirror

Off/On

Privacy Masking

Off/On (4 area, Rectangle)

Audio

Compression

G.711a/G.711Mu/AAC

Intelligence

IVS

Tripwire, Intrusion, Object Abandon/Missing

Advanced Intelligent Functions

Fire detection & alarm

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x

Interoperability

ONVIF Profile S & G, PSIA, CGI

Streaming Method

Unicast/Multicast

Max. User Access

10 Users/20 Users

Edge Storage

micro SD (128GB)

Memory status display (Normal/Error/Active/ Formatting/Lock),

NAS (Network Attached Storage), Local PC for instant recording

Web Viewer

Management Software

SmartPSS, DSS

Smart Phone

Android, Ios

Certifications

Certification

CE (EN 60950: 2000) FCC (FCC Part 15 SubpartB )

Interface

Video Interface

1.0Vp-p/75Ω, PAL/NTSC (HDCVI Optional)

Audio Interface

1 Input

RS485

NA

Alarm

2/1 In/Out

Electrical

Power Supply

AC 24V/DC 12V/PoE

Power Consumption

Max. 7W

Environmental

Operating Condition

-40°C ~ +60°C (-40°F ~ +140°F)/Less than 95% RH

* Start up should be done at above -40°C (-40°F)

Strorage Conditions

-40°C ~ +70°C (-40°F ~ +158°F)/Less than 95% RH

Ingress Protection

IP67

Construction

Casing

Metal

Dimensions

291mm× 103mm× 97mm (11.46" x 4.06" x 3.82")

Net Weight

1.37Kg (3.02 lb)

Gross Weight

1.7Kg (3.75 lb)
